Electric Winch Series 3 (9500lb) Water Resistant

› Specifications

• Rated line pull 9500 lbs (42.23kN)

• Gear reduction ratio 233:1 (12V)

• Motor Series wound (Input power)

• 5.5 hp / 4.2kW (DC12V)

• Control Remote switch, 12ft (3.7m) lead

• Gear train 3 stage planetary gear train

• Clutch Sliding ring gear

• Braking Action Automatic in-the-drum

• Fairlead 4-way roller fairlead

• Remote Control Through control box and switch

• Battery Recommended: 650CCA minimum for winching

• Battery Leads 2 gauge, 72" (1.83mm)

• Overall dimensions 21.46" (L) x 6.30" (W) x 9.00"(H),

• 545(L) mm x 160 (W) mm x 226(H) mm

• Drum Size 2.48" (D) x 8.8"(L), 63(D) mm x 224(L) mm

• Cable 3/8" (D) x85"(L), 9.2mm (D) x 26m (L)

• Weight 69.7lbs (31.6 kg), 70.5lbs (32kg) (-S TYPE)

• Mounting Bolt Pattern 10.00+0.015" x 4.50+0.010" (254 x 114.3mm)

• Warranty 3 year warranty



PART NUMBER	DESCRIPTION
TEW9500WP	ELECTRIC WINCH Series 3 WATERRESISTANT

› Duty Cycle

Line Speed and Motor Current (First Layer)

Line Pull	Line Speed	Motor Current
	ft/min (m/min)	Amps (Max)
lb(kN)	12V DC	12V DC
0	22.05(6.8)	65
2000(8.89)	11.67(3.6)	179
3000(13.33)	10.05(3.1)	203
6000(26.67)	9.08(2.8)	286
8000(35.56)	7.13(2.2)	330
9500(42.23)	6.16(1.9)	365

Line Pull and cable capacity

Layer of cable	Rated line pull per Layer	Cable capacity per Layer
	lb(kN)	ft (m)
1	9500(42.23)	15.1(4.6)
2	7600(33.78)	34.1(10.4)
3	6200(27.56)	57.7(17.6)
4	5400(24.00)	83.7(25.5)
